Then copy the required video clips to the hard drive.
#Huawei e3531 specifications Pc#
To do this, remove the memory card from the DVR and connect it to a PC using an appropriate card reader. How do I backup the required video files? All power supply units that come with Gazer DVRs can be plugged into 24V car power systems. The availability of international certification also confirms the compliance with stated specifications, which attests to the DVR's high quality.Ĭan the DVR be powered from the car's 24V cigarette lighter socket?
It means that using a Gazer DVR is absolutely legal and safe.
The main purpose or a car DVR is to gather data to be used as evidence in controversial situations and in case of a traffic accident.Īll Gazer DVRs have international certification. The resolution is expressed in television lines (TVL) and indicates the number of elements in a television image line.Ī car DVR (digital video recorder) is a device designed for video and audio capture of everything happening around a moving or parked car. The specifications for this signal are 540 TVL (720х576) for PAL standard and 500 TVL (720х480) for NTSC. Rear view cameras use an analogue signal to transmit the image onto the monitor. What is the image resolution of Gazer rear view cameras? Once the green wire is cut, the camera will start operating in NTSC standard. One can switch from PAL to NTSC mode using the green wire on the camera input. Please, make sure that the camera and the car stereo operate in the same video standard (PAL or NTSC).
Gazer CC125 renders a black and white image when connected to a stock car stereo. However, the timer function will be unavailable should you use СС155 or СС125 cameras with СС100 cable. Is it possible to use Gazer CC100 connection cable with СС125 and СС155 cameras? J2 jumper located closer to the edge of the relay unit circuit board is responsible for activating the camera’s turn off delay after the reverse gear is disengaged (the image from the rear view camera will be displayed on the monitor for 10 sec after the reverse gear is disengaged). J1 jumper located closer to the center of the circuit board is responsible for switching the camera on for 10 sec when ACC signal is supplied (i.e. J1 and J2 jumpers available on the relay unit circuit board enable the camera to operate in timer modes. There are two jumpers on relay units of Gazer CC125 and Gazer CC155 rear view cameras. Please, go to system calibration settings and enable "mirroring" for each camera. The mirror effect is due to installation of NTSC only cameras. Gazer CKR4400: how many video clips can be stored on a 64 GB memory card?Ī 64 GB memory card can hold about 650 video clips, which is roughly equal to 1 month of using your Gazer surround view system.Īfter Gazer CKR4400 surround view system is installed and the central unit connected, all cameras except the rear one transmit a mirrored image. Which USB modems are supported by Gazer video interfaces? VI700A If it is impossible to open the "Screen calibration" application using the touchscreen, please, connect a USB mouse and open the application with it. Make sure that an SD card is inserted in the video interface. Please, open the "Screen calibration" application and repeat the calibration process.
What is to be done if Gazer VI700A video interface responds to touch gestures incorrectly?
